Features
- The Multilex Valve series controls many types of fluids, including water, air, kerosene, and oil.
Purpose
- For ON/OFF control of water, air, kerosene, and oil fluids
Specifications in detail
Operating pressure: 0 to 0.6MPa (fluids used: air, water, kerosene), 0 to 0.5MPa (oil)
Fluid temperature: -10 to 60°C (no freezing)
Open frame type Lead wire (equivalent to IP65): 300mm
Effective cross-sectional area ((MM2)): 100
Connection size: Rc1/2
Operation method: Pilot kick type
Power supply (V): DC24
Number of ports: 2
Operating pressure (MPa): 0 to 1 (fluid used: air)
Fluid used: air, water, low vacuum, kerosene, oil
Fluid temperature (°C): -10 to 60 (no freezing)
Cv value: 4.5
Sonic conductance (C [dm (cubed)/(S bar)]): 20
CKD ADK11-15A-03A-DC24V
