Features
- Used to create and clean screw holes.
- For repairing and creating normal threads.
Purpose
- Workpiece materials: iron, light metals.
- Repair and creation of normal threads.
Specifications in detail
Tip: Tip
precision: JIS Class 3
Precision notation: JIS Class 3
Nominal size: M30
Pitch (mm): 3.5
Thread length (mm): 48
Total length (mm): 135
Shank diameter (mm): 23
Shank square section (mm): 17
Pilot hole diameter (mm): 26.5
Machined thread: Metric thread
Surface treatment: Non-coated
TRUSCO T-HT30X3.5-1
