Features
- This pump is used when installing medium to large bearings with tapered bores using hydraulic equipment.
- Medium and large SKF bearings with tapered bore are often mounted hydraulically.
- SKF tools and techniques ensure that bearings are mounted in a controlled and precise manner, contributing to longer bearing life.
- The technique can also be applied to other annular components such as gears and railway wheels.
- SKF hydraulic tools and techniques enable the safe and controlled removal of bearings and similar components on cylindrical or tapered shafts.
Purpose
- For SKF OK coupling hydraulic chambers.
- For all sizes of SKF hydraulic nuts.
- For oil injection applications requiring pressures up to 50MPa.
Specifications in detail
Large oil tank with 2700 cm3 capacity
Equipped with overpressure valve and pressure gauge connection
Packed in sturdy protective case
1 litre spare installation oil included
Effective oil volume (L): 2.7
Discharge volume per operation (ml) high pressure: 3.5
Maximum operating pressure (MPa) high pressure: 50
Discharge port diameter: G1/4
Maximum operating force (N): 310
SKF TMJL 50
