Features
- This plug comes with an earth check lamp. Simply insert the plug into an outlet and you can see by looking at the lamp whether the earth wire is properly grounded.
- Equipped with a breaker to prevent dangerous electric leakage.
- It comes with a "drum stopper" that stops the rotation of both the cable and the drum at the same time.
- Comes with an earth check lamp.
Note
- The breaker is for leakage current protection only.
- If used while rolled up, there is a risk of burning.
- Do not use outdoors in rainy weather.
Specifications in detail
AC100V
Maximum current: 15A
Dedicated plug for earth leakage protection
: Pop-in plug
Equipped with a "drum stopper" that stops the rotation of the cable and drum at the same time Earth
leakage breaker sensitivity 15mA
Wire type: VCT
Wire specification length (m): 30
Wire specification thickness ((mm2)): 2.0
Wire specification number of
cores (C): 3 Rated current (A): 5
Maximum current (A): 15
Outlet specification rating: 15A/100V Earthed
Outlet specification shape: (3-phase 1)
Number of outlet specifications: 4
Temperature sensor: Automatic reset type
Power lamp: Yes
Ground terminal: Yes
2P/3P compatible plug: Yes
Earth leakage breaker specification: Dedicated for earth leakage protection
Rated voltage (V): 100
NICHIDO GNF-EB34
