Mũi khoan Solid Carbide FUTURO kiểu 8xD -# 255580

Mũi khoan Solid Carbide FUTURO kiểu 8xD -# 255580

Mũi khoan Solid Carbide FUTURO kiểu 8xD -# 255580

Thương hiệu: FUTURO Mã sản phẩm: (Đang cập nhật...)

Liên hệ

Các thương hiệu bán chạy

Thông tin sản phẩm

Mã đặt hàng	d1	l2	l1	d2	l3	Mã đặt hàng	d1	l2	l1	d2	l3	Mã đặt hàng	d1	l2	l1	d2	l3
	mm	mm	mm	mm	mm		mm	mm	mm	mm	mm		mm	mm	mm	mm	mm
255580.0030	3	30	70	6	36	255580.0470	6.7	66	106	8	36	255580.1440	10.4	106	155	12	45
255580.0031	3.1	30	70	6	36	255580.0500	6.8	66	106	8	36	255580.1500	10.5	106	155	12	45
255580.0032	3.2	30	70	6	36	255580.0590	6.9	76	116	8	36	255580.1560	10.6	106	155	12	45
255580.0033	3.3	30	70	6	36	255580.0600	7	76	116	8	36	255580.1570	10.7	106	155	12	45
255580.0034	3.4	30	70	6	36	255580.0610	7.1	76	116	8	36	255580.1580	10.8	106	155	12	45
255580.0035	3.5	35.5	75	6	36	255580.0620	7.2	76	116	8	36	255580.1590	10.9	106	155	12	45
255580.0036	3.6	35.5	75	6	36	255580.0630	7.3	76	116	8	36	255580.1600	11	106	155	12	45
255580.0037	3.7	35.5	75	6	36	255580.0640	7.4	76	116	8	36	255580.1610	11.1	114	163	12	45
255580.0038	3.8	37.5	75	6	36	255580.0700	7.5	76	116	8	36	255580.1620	11.2	114	163	12	45
255580.0039	3.9	37.5	75	6	36	255580.0760	7.6	76	116	8	36	255580.1630	11.3	114	163	12	45
255580.0040	4	37.5	75	6	36	255580.0770	7.7	76	116	8	36	255580.1640	11.4	114	163	12	45
255580.0041	4.1	37.5	75	6	36	255580.0800	7.8	76	116	8	36	255580.1700	11.5	114	163	12	45
255580.0042	4.2	37.5	75	6	36	255580.0890	7.9	76	116	8	36	255580.1760	11.6	114	163	12	45
255580.0043	4.3	45	85	6	36	255580.0900	8	76	116	8	36	255580.1770	11.7	114	163	12	45
255580.0044	4.4	45	85	6	36	255580.0910	8.1	87	131	10	40	255580.1780	11.8	114	163	12	45
255580.0045	4.5	45	85	6	36	255580.0920	8.2	87	131	10	40	255580.1790	11.9	114	163	12	45
255580.0046	4.6	45	85	6	36	255580.0930	8.3	87	131	10	40	255580.1800	12	114	163	12	45
255580.0047	4.7	45	85	6	36	255580.0940	8.4	87	131	10	40	255580.1810	12.2	133	182	14	45
255580.0048	4.8	50	90	6	36	255580.1000	8.5	87	131	10	40	255580.1820	12.5	133	182	14	45
255580.0049	4.9	50	90	6	36	255580.1060	8.6	87	131	10	40	255580.1830	12.7	133	182	14	45
255580.0100	5	50	90	6	36	255580.1070	8.7	87	131	10	40	255580.1840	13	133	182	14	45
255580.0110	5.1	50	90	6	36	255580.1080	8.8	87	131	10	40	255580.1850	13.5	133	182	14	45
255580.0120	5.2	50	90	6	36	255580.1090	8.9	87	131	10	40	255580.1860	14	133	182	14	45
255580.0130	5.3	50	90	6	36	255580.1100	9	87	131	10	40	255580.1870	14.2	152	204	16	48
255580.0140	5.4	57	97	6	36	255580.1110	9.1	95	139	10	40	255580.1880	14.5	152	204	16	48
255580.0200	5.5	57	97	6	36	255580.1120	9.2	95	139	10	40	255580.1890	15	152	204	16	48
255580.0260	5.6	57	97	6	36	255580.1130	9.3	95	139	10	40	255580.1900	15.5	152	204	16	48
255580.0270	5.7	57	97	6	36	255580.1140	9.4	95	139	10	40	255580.1910	16	152	204	16	48
255580.0280	5.8	57	97	6	36	255580.1200	9.5	95	139	10	40	255580.1920	16.5	171	223	18	48
255580.0290	5.9	57	97	6	36	255580.1260	9.6	95	139	10	40	255580.1930	17	171	223	18	48
255580.0300	6	57	97	6	36	255580.1270	9.7	95	139	10	40	255580.1940	17.5	171	223	18	48
255580.0310	6.1	66	106	8	36	255580.1280	9.8	95	139	10	40	255580.1950	18	171	223	18	48
255580.0320	6.2	66	106	8	36	255580.1290	9.9	95	139	10	40	255580.1960	18.5	190	244	20	50
255580.0330	6.3	66	106	8	36	255580.1300	10	95	139	10	40	255580.1970	19	190	244	20	50
255580.0340	6.4	66	106	8	36	255580.1310	10.1	106	155	12	45	255580.1980	19.5	190	244	20	50
255580.0400	6.5	66	106	8	36	255580.1400	10.2	106	155	12	45	255580.1990	20	190	244	20	50
255580.0460	6.6	66	106	8	36	255580.1430	10.3	106	155	12	45
