| Mã đặt hàng | d1 | Dung sai | d2 | l2 | l1 | l3 | Z |
| mm | mm | mm | mm | mm | |||
| 284320.0100 | 3.97 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0200 | 3.98 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0300 | 3.99 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0400 | 4.00 | H7 | 6 | 12 | 75 | 39 | 4 |
| 284320.0500 | 4.01 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0600 | 4.02 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0700 | 4.03 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.0800 | 4.50 | H7 | 6 | 12 | 75 | 39 | 4 |
| 284320.0900 | 4.97 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1000 | 4.98 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1100 | 4.99 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1200 | 5.00 | H7 | 6 | 12 | 75 | 39 | 4 |
| 284320.1300 | 5.01 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1400 | 5.02 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1500 | 5.03 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1600 | 5.50 | H7 | 6 | 12 | 75 | 39 | 4 |
| 284320.1700 | 5.97 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1800 | 5.98 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.1900 | 5.99 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.2000 | 6.00 | H7 | 6 | 12 | 75 | 39 | 4 |
| 284320.2100 | 6.01 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.2200 | 6.02 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.2300 | 6.03 | 0/+0,004 | 6 | 12 | 75 | 39 | 4 |
| 284320.2400 | 6.50 | H7 | 8 | 16 | 100 | 64 | 6 |
| 284320.2500 | 7.00 | H7 | 8 | 16 | 100 | 64 | 6 |
| 284320.2600 | 7.50 | H7 | 8 | 16 | 100 | 64 | 6 |
| 284320.2700 | 7.97 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.2800 | 7.98 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.2900 | 7.99 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.3000 | 8.00 | H7 | 8 | 16 | 100 | 64 | 6 |
| 284320.3100 | 8.01 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.3200 | 8.02 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.3300 | 8.03 | 0/+0,004 | 8 | 16 | 100 | 64 | 6 |
| 284320.3400 | 8.50 | H7 | 10 | 20 | 100 | 60 | 6 |
| 284320.3500 | 9.00 | H7 | 10 | 20 | 100 | 60 | 6 |
| 284320.3600 | 9.50 | H7 | 10 | 20 | 120 | 80 | 6 |
| 284320.3700 | 9.97 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.3800 | 9.98 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.3900 | 9.99 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.4000 | 10.00 | H7 | 10 | 20 | 120 | 80 | 6 |
| 284320.4100 | 10.01 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.4200 | 10.02 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.4300 | 10.03 | 0/+0,004 | 10 | 20 | 120 | 80 | 6 |
| 284320.4400 | 10.50 | H7 | 12 | 20 | 120 | 75 | 6 |
| 284320.4500 | 11.00 | H7 | 12 | 20 | 120 | 75 | 6 |
| 284320.4600 | 11.50 | H7 | 12 | 20 | 120 | 75 | 6 |
| 284320.4700 | 11.97 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.4800 | 11.98 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.4900 | 11.99 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.5000 | 12.00 | H7 | 12 | 20 | 120 | 75 | 6 |
| 284320.5100 | 12.01 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.5200 | 12.02 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.5300 | 12.03 | 0/+0,004 | 12 | 20 | 120 | 75 | 6 |
| 284320.5400 | 13.00 | H7 | 14 | 22 | 130 | 85 | 6 |
| 284320.5500 | 14.00 | H7 | 14 | 22 | 130 | 85 | 6 |
| 284320.5600 | 15.00 | H7 | 16 | 22 | 130 | 82 | 6 |
| 284320.5700 | 16.00 | H7 | 16 | 25 | 150 | 102 | 6 |
| 284320.5800 | 17.00 | H7 | 18 | 25 | 150 | 102 | 8 |
| 284320.5900 | 18.00 | H7 | 18 | 25 | 150 | 102 | 8 |
| 284320.6000 | 19.00 | H7 | 20 | 25 | 150 | 100 | 8 |
| 284320.6100 | 20.00 | H7 | 20 | 25 | 150 | 100 | 8 |
