| Mã đặt hàng | d1 | d2 | l2 | l1 | l3 | Z | Mã đặt hàng | d1 | d2 | l2 | l1 | l3 | Z |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | ||||
| 282120.0100 | 2.0 | 2 | 11 | 49 | 24 | 4 | 282120.1100 | 12.0 | 10 | 44 | 151 | 111 | 6 |
| 282120.0200 | 3.0 | 3 | 15 | 61 | 33 | 6 | 282120.1200 | 13.0 | 10 | 44 | 151 | 111 | 6 |
| 282120.0300 | 4.0 | 4 | 19 | 75 | 47 | 6 | 282120.1300 | 14.0 | 14 | 47 | 160 | 115 | 8 |
| 282120.0400 | 5.0 | 5 | 23 | 86 | 58 | 6 | 282120.1400 | 15.0 | 14 | 50 | 162 | 117 | 8 |
| 282120.0500 | 6.0 | 6 | 26 | 93 | 57 | 6 | 282120.1500 | 16.0 | 14 | 52 | 170 | 125 | 8 |
| 282120.0600 | 7.0 | 8 | 31 | 109 | 73 | 6 | 282120.1600 | 17.0 | 14 | 54 | 175 | 130 | 8 |
| 282120.0700 | 8.0 | 8 | 33 | 117 | 81 | 6 | 282120.1700 | 18.0 | 14 | 56 | 182 | 137 | 8 |
| 282120.0800 | 9.0 | 10 | 36 | 125 | 85 | 6 | 282120.1800 | 19.0 | 16 | 58 | 189 | 141 | 8 |
| 282120.0900 | 10.0 | 10 | 38 | 133 | 93 | 6 | 282120.1900 | 20.0 | 16 | 60 | 195 | 147 | 8 |
| 282120.1000 | 11.0 | 10 | 41 | 142 | 102 | 6 |
