| d1 | d2 | l2 | l1 | d1 | d2 | l2 | l1 |
| mm | mm | mm | mm | mm | mm | mm | mm |
| 0.95...1.05 | 1 | 5.5 | 34 | 6.95...7.05 | 7.1 | 31 | 109 |
| 1.45...1.50 | 1.5 | 8 | 40 | 7.45...7.50 | 7.1 | 31 | 109 |
| 1.51...1.55 | 1.6 | 9 | 43 | 7.51...7.55 | 8 | 33 | 117 |
| 1.95...2.05 | 2 | 11 | 49 | 7.95...8.05 | 8 | 33 | 117 |
| 2.45...2.55 | 2.5 | 14 | 57 | 8.45...8.50 | 8 | 33 | 117 |
| 2.95...3.03 | 3 | 15 | 61 | 8.51...8.55 | 9 | 36 | 125 |
| 3.04...3.05 | 3.2 | 16 | 65 | 8.95...9.05 | 9 | 36 | 125 |
| 3.45...3.55 | 3.5 | 18 | 70 | 9.45...9.50 | 9 | 36 | 125 |
| 3.95...4.05 | 4 | 19 | 75 | 9.51...9.55 | 10 | 38 | 133 |
| 4.45...4.55 | 4.5 | 21 | 80 | 9.95...10.05 | 10 | 38 | 133 |
| 4.95...5.05 | 5 | 23 | 86 | 10.45...10.55 | 10 | 38 | 133 |
| 5.45...5.55 | 5.6 | 26 | 93 | 10.95...11.05 | 10 | 41 | 142 |
| 5.95...6.03 | 5.6 | 26 | 93 | 11.45...11.55 | 10 | 41 | 142 |
| 6.04...6.05 | 6.3 | 28 | 101 | 11.95...12.00 | 10 | 44 | 151 |
| 6.45...6.55 | 6.3 | 28 | 101 |
| d1 | d2 | l2 | l1 | d1 | d2 | l2 | l1 |
| mm | mm | mm | mm | mm | mm | mm | mm |
| 0.95...1.05 | 1 | 5.5 | 34 | 6.95...7.05 | 7.1 | 31 | 109 |
| 1.45...1.50 | 1.5 | 8 | 40 | 7.45...7.50 | 7.1 | 31 | 109 |
| 1.51...1.55 | 1.6 | 9 | 43 | 7.51...7.55 | 8 | 33 | 117 |
| 1.95...2.05 | 2 | 11 | 49 | 7.95...8.05 | 8 | 33 | 117 |
| 2.45...2.55 | 2.5 | 14 | 57 | 8.45...8.50 | 8 | 33 | 117 |
| 2.95...3.03 | 3 | 15 | 61 | 8.51...8.55 | 9 | 36 | 125 |
| 3.04...3.05 | 3.2 | 16 | 65 | 8.95...9.05 | 9 | 36 | 125 |
| 3.45...3.55 | 3.5 | 18 | 70 | 9.45...9.50 | 9 | 36 | 125 |
| 3.95...4.05 | 4 | 19 | 75 | 9.51...9.55 | 10 | 38 | 133 |
| 4.45...4.55 | 4.5 | 21 | 80 | 9.95...10.05 | 10 | 38 | 133 |
| 4.95...5.05 | 5 | 23 | 86 | 10.45...10.55 | 10 | 38 | 133 |
| 5.45...5.55 | 5.6 | 26 | 93 | 10.95...11.05 | 10 | 41 | 142 |
| 5.95...6.03 | 5.6 | 26 | 93 | 11.45...11.55 | 10 | 41 | 142 |
| 6.04...6.05 | 6.3 | 28 | 101 | 11.95...12.00 | 10 | 44 | 151 |
| 6.45...6.55 | 6.3 | 28 | 101 |
