| Mã đặt hàng | d1 | h | b | d2 | d3 | d4 | k | Packaging |
| mm | mm | mm | mm | mm | mm | mm | ||
| 862110.0010 | M6 | 27.5 | 12 | 27 | 16 | 14 | 6.5 | 100 |
| 862110.0020 | M8 | 36 | 13 | 36 | 20 | 20 | 8 | 100 |
| 862110.0030 | M10 | 45 | 17 | 45 | 25 | 25 | 10 | 50 |
| 862110.0040 | M12 | 53 | 20.5 | 54 | 30 | 30 | 12 | 25 |
| 862110.0060 | M16 | 62 | 27 | 63 | 35 | 35 | 14 | 25 |
| 862110.0070 | M20 | 71 | 30 | 72 | 40 | 40 | 16 | 10 |
| 862110.0080 | M24 | 90 | 36 | 90 | 50 | 50 | 20 | 1 |
| 862110.0090 | M30 | 109 | 45 | 108 | 65 | 50 | 24 | 1 |
| 862110.0100 | M36 | 128 | 54 | 126 | 75 | 70 | 28 | 1 |
| 862110.0110 | M42 | 147 | 63 | 144 | 85 | 80 | 32 | 1 |
| 862110.0130 | M48 | 168 | 68 | 166 | 100 | 90 | 38 | 1 |
| 862110.0140 | M52 | 187 | 78 | 184 | 110 | 100 | 42 | 1 |
| 862110.0150 | M56 | 187 | 78 | 184 | 110 | 100 | 42 | 1 |
| 862110.0160 | M64 | 208 | 90 | 206 | 120 | 110 | 48 | 1 |
| 862110.0170 | M72 | 260 | 100 | 260 | 150 | 140 | 60 | 1 |
Hoist rings M6 - M72 BRW - # 862110
